Discontinued
Post ProductPortable Combination Gas Detector
RX-515
Features
・Dual range detection of CH4 in %vol and %LEL
・Unique gas combinations include: CH4/O2/CO/CO2
・Accurately measure CH4 from inerted tanks with infrared sensor
・Intrinsically safe design
・Datalogging (Max 30hours of interval trend)
Sampling method |
Suction type |
Principle of detection |
Non-Dispersive Infrared Method, Potentiostatic Electrolysis Method, Membrane Type Galvanic Cell Method |
Detection range |
0 to 100%LEL,5 to 100vol%(CH4) |
Explosion protected construction |
Flameproof enclosures + Intrinsic safety |
Approvals |
Japan Ex, ATEX, MED, ABS |
Power source |
Alkaline batteries (Size C) 4 pcs. |
Continuous operation |
Approx. 30 hours (no alarm, no light, at 25℃) |
Dimensions |
Approx. 200(W) x 80(H) x 142(D)mm |
Weight |
Approx. 1.8kg (including batteries) |
Operating temperature range |
-10℃ to 50℃ (no sudden changes) |
Operating humidity range |
0 to 90%RH (no condensing) |
